40-1000ml máquina de recheo dixital e chea de líquido totalmente automática

Descrición do produto

The filling line mainly consists of two parts, filling and capping, with a total length of 6 meters. It can connect aluminum foil sealing machine, labeling machine and inkjet printer to form a higher production line of automation. Adopt liquid crystal touch screen operation interface, PLC programmable control system, adopt equal liquid level control filling time to realize filling with different measurement. The utility model has the advantages of simple structure, universal size, and no bottle replacement, and can be adjusted when the bottle is changed. Widely used in oral liquid, disinfectant, juice, soy sauce, vinegar, pesticides, chemicals, detergents, lubricants and cosmetics and other liquid filling. Filling accurate metering, no bubbles, no drip. The utility model is suitable for filling various 40-1000ml bottles (including special-shaped bottles).

40-1000ml máquina de recheo dixital e chea de líquido totalmente automática

Función:

1. The machine is suitable for filling different specifications of containers, and can change the filling specifications in a few minutes.

2. Replace filling specifications, no need to add equipment, just need to make adjustments to complete.

3. Touch operation screen, can display the status of production, operating procedures, filling etc..

40-1000ml máquina de recheo dixital e chea de líquido totalmente automática

Metering range

40-1000ml

Precisión de recheo

±1%(>100ml)

Velocidade de recheo

0-900Bottles/hour

0-1500Bottles/hour

0-2400Bottles/hour

0-3600Bottles/hour

0-4800Bottles/hour

Presión do aire

0,5-0,7mpa

Consumo de gas

200L / t

200L / t

200L / t

400L/t

400L/t

Voltaxe

380V50HZ

Potencia

1.0KW

1.0KW

1.0KW

1,5KW

1,5KW

Peso

260KG

260KG

260KG

400KG

500KG

Dimensións xerais

(L*W*H)CM

400*80*210

400*80*210

400*80*210

600*83*220

600*83*220

♥ Professinoal peson reply your questions

♥ One yearwarranty for you

♥ Perfect and carefulafter-sale service

♥ Fast delivery for you

♥ 24 hours on-line service for you

♥ 3 CAD engineer design customer machine and mould

FAQ

Q: Why don't person reply to me?

R: A nosa persoa está 24 horas en liña. Cando ninguén che responda, deixe as túas necesidades no correo electrónico ou na ferramenta de chat, responderemos o antes posible.

Q: The output of the machine is much ?

A:We have a lot of machines, you can according to your need to choose the corresponding production machine type .

Q: How do you make your price?

R: Facemos o prezo segundo o noso custo integral. E o noso prezo será máis baixo que a empresa comercial, porque nós estamos a manufacture.You terá prezo competitivo e mellor calidade.
